ETI EZ Install Direct Indirect Architectural Wrap Light

ETi SSL’s WR EZ Install Direct|Indirect Architectural Wrap Light Series provides efficient and economical ambient illumination for a wide range of ambient applications. Its unique design architecture makes for a very flexible project solution suitable for remodel, retrofit or new construction commercial and institutional projects.

This wrap series can provide direct illumination only (~3,977 lumens), indirect illumination only (~2,725 lumens) or both (6,702 lumens) that are easily controlled by simply toggling the wall switch on & off within 3-seconds of each other. The direct illumination LED array is paired with a low glare diffuse optical lens system that delivers an extremely uniform light distribution optimized for most general open ambient applications. A separate indirect LED array provides soft general up light illumination. Helping to create a warm and inviting architectural effect and feel within the space.

Three different primary mounting options (direct surface mount, suspension mount or pendant/stem mount) can also be paired with the ability for continuous row or end-to-end installation. Making for an extremely flexible and versatile architectural design solution.

Key Product Features:

• Direct illumination only (~3,977 LM), indirect only (~2,725 LM) or both (6,702 LM)
• Simply toggle the wall switch on & off within 3-seconds to switch lighting modes
• Can connect up to 8 fixtures
• Uniform illumination w/ diffusing lens for reduced glare & visual comfort
• (3) mounting options: surface, suspension (included) or pendant/stem (optional)
• Combine mounting options w/ continuous row mounting bracket (included)
• 120 LPW provides 60+% in energy savings vs. legacy fluorescent luminaires
• DLC qualified for energy savings & potential rebate eligibility
• 4000K, 80+ CRI standard for accurate color rendering & visual performance
• Reported L89/60,000, Projected L70 @ 180,000 hours (per IES TM21)
• Formed steel housing, die-cast end caps w/ hinged lens design

• Standard -20° to 45° C (-4° to 113° F) high ambient temperature rating

• 120-277V drivers w/ 0-10V dimming capability as standard
• Optional side mount occupancy sensors for added energy savings & code compliance
• Call or email for pricing on optional EM battery backup for safety & code compliance (CA Title 20 MAEDBS) *** If fixture will be installed with a BBU (battery backup), please note surface mount installation is not recommended, as the BBU will turn the light on to indirect light which is not ideal when fixture is flush to the ceiling.

Spec Sheet:
